EMC Lesson 3: Instrumentation: Discrete and Sensory

This program shows how to calibrate and bench test the most common components found in your plant. Your people will know how to test and calibrate these components before installation to avoid costly mistakes and delays.

This program also explains how valves operate, and how to wire them. Now everyone will be able to quickly identify the real problem and avoid wasting time replacing unnecessary components.

Bench Test & Calibrate Components—Cut Installation Time & Costs

• Choose the correct photoelectric sensor for your application
• Apply, install, and troubleshoot limit, photoelectric, and proximity switches
• Wire and understand the inner workings of 2, 3, and 4-way valves
• Cut your installation time—bench test and calibrate pressure devices before installation
• Clogged ports or a bad solenoid—learn to spot the difference and avoid replacing unnecessary components
