Understanding, Maintaining and Troubleshooting ControlLogix Systems -with- Studio 5000 Designer Software

Master Essential ControlLogix Skills and Maximize Uptime.

Our comprehensive 10-module ControlLogix Systems Training Series equips every maintenance technician with the fundamental Allen-Bradley ControlLogix 5000 PLC skills they need for efficient and effective troubleshooting. By sharpening expertise in this critical environment, you’ll see increased business competitiveness through reduced downtime and improved operational efficiency. (Includes one physical ControlLogix Handbook Collection and PDF access via the Tablet Training Portal App).

Module 1: Introduction to the ControlLogix—General Structure, Number Systems, and Basics of Boolean Logic
Module 2: ControlLogix Hardware Composition, I/O Structure and Architecture—Introduction to Tags
Module 3: Navigating the Studio 5000 Software and Creating, Opening and Understanding Projects
Module 4: Connecting to the Controller—Establishing RSLinx Connection to the Network
Module 5: ControlLogix Project Organization and Frequently Used Tag Structures
Module 6: Troubleshooting Ladder Diagram Logic in the ControlLogix System
Module 7: Creating and Editing Tags and Code—Documenting Troubleshooting Changes
Module 8: Troubleshooting Using the Studio 5000 Software—Using I/O Forcing and Toggling Functions
Module 9: Troubleshooting ControlLogix Hardware—Discrete and Analog I/O
Module 10: Troubleshooting Remote I/O, Controller and Power Supply—Using the Trend and Compare Tools to Troubleshoot
